Portal A Wireless Gateway
Portal A
.png)
-
Overview
The Portal A is a versatile wireless gateway that offers seamless connectivity and reliable performance. It supports various network options, including Wi-Fi, Gigbat Ethernet, and optional modules like LoRa and 4G. The Portal A is ideal for IoT applications requiring long-range, low-power communication.
-
Main Features• High-performance Quad Core Cortex-A55 CPU up to 1.8GHz
• Built-in Wi-Fi, Gigbat Ethernet, and optional LoRa, 4G, and GPS modules for diverse network options
• Convenient set-up and easy management using a mobile phone
• Expand coverage range with an optional LoRa antenna
• Support OTA automatic update, stable and reliable
Specification
|
System |
|
|
CPU |
RK3566, 4 x ARM Cortex-A55, 1.8GHz, comes with an integrated neural processing unit (NPU) that delivers 1TOPS of performance. |
|
Memory |
4GB LPDDR4 |
|
Storage |
64GB eMMC |
|
Clipper Chip |
ATECC608 |
|
OS |
Debian, Ubuntu |
|
Communication |
|
|
LAN |
1 x Gigabit Network |
|
LoRa |
1 x LoRa module (optional), support 470MHz, 868MHz and 915MHz |
|
WIFI & BT |
1 x WIFI & BT module |
|
4G |
1 x 4G module (optional) |
|
GPS |
1 x GPS module (optional) |
|
I/O Interfaces |
|
|
SIM |
1 x SIM slot |
|
Button |
1 x Bluetooth Pairing Button |
|
LED |
1 x System LED, 1 x Status LED |
|
Antennas |
1 x LoRa Antenna (optional, 4dBi, 1m extension cable, with a strong magnetic chuck), 1 x WiFi Antenna (2.4GHz, 3dBi), 1 x 4G Antenna (optional), 1 x GPS Antenna (optional) |
|
RTC |
1 x RTC |
|
USB |
1 x USB 3.0 |
|
Power Supply |
|
|
Power Input |
DC 12V/2A |
|
Mechanical Structure |
|
|
Dimension |
158 x 117.8 x 26mm |
|
Material |
Aluminum alloy |
|
Net Weight |
348g |
|
Operating Temp. |
0℃~70℃ |
Document
