DEBIX 5" 800 x 480 TFT LCD Monitor
DEBIX TD050A
-
Overview
DEBIX TD050A LCD monitor comes with a 800 x 480 display which has the size of 5.0". With LVDS display interface and USB touch interface, it is composed of a color TFT-LCD panel, driver IC, FPC and a backlight unit. The driver element is a-Si TFT active matrix.
Compatibility
Compatible with all DEBIX series
.png)
-
.jpg)
Main Features• 5.0" 800*480 display size
• IPS with Normally Black display mode
• LVDS Interface
• RGB-stripe colour arrangement
Specification
|
Parameter |
|
|
Model |
DEBIX TD050A |
|
LCD Size |
5 inch (Diagonal) |
|
Driver Element |
a-Si TFT action matrix |
|
Resolution |
800 x 480 |
|
Display Mode |
IPS with Normally Black |
|
Active Area (W x H) |
108.00mm x 64.80mm |
|
Outline Dimension (W x H x D) |
120.80mm x 75.95mm x 2.80mm |
|
Color Arrangement |
RGB-stripe |
|
LVDS Interface |
1 x LVDS, the connector is 20Pin header |
|
Touch Interface |
1 x USB, the connector is 4Pin header |
|
Luminance |
300 cd/m² (Typ.) |
|
Operating Temp. |
-20°C to 70°C |
|
Storage Temp. |
-30°C to 80°C |
|
Input Voltage |
DC 5V |
|
Net Weight |
96g (±0.5g) |
|
Gross Weight |
228g (±0.5g) |
