OKdo 5" 800 x 480 TFT LCD Monitor
2539306 (RS stock number)
-
Overview
The OKdo LCD monitor comes with a 800 x 480 display which has the size of 5.0". With LVDS display interface and USB touch interface, it supports normal black and IPS modes. The driver element is a-Si TFT active matrix.
Compliance
· RoHS
· Meet the administrative and technical requirements of the ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards
-
Main Features• 5.0" 800*480 display size
• Normal black, IPS display modes
• LVDS Interface
• RGB-stripe colour arrangement
Specification
| Item | Specification |
| LCD size | 5.0"(Diagonal) |
| Driver element | a-Si TFT active matrix |
| Resolution | 800 x 3(RGB) x 480 |
| Display mode | Normally black, IPS |
| Dot pitch | 0.135(W) x 0.135(H)mm |
| Active area | 108(W) x 64.8(H)mm |
| Outline dimension | 130.70(W) x 85.80(H) x 4.68(D)mm |
| TP surface treatment | 6H |
| Colour arrangement | RGB-stripe |
| LCM interface | Digital |
| Touch interface | USB |
| Operating temp. | -20°C to 70°C |
| Storage temp. | -20°C to 70°C |
Document
